Patikima apsauga nuo dulkių ir atsparumas vandeniui su tvirtu IP67 klasės korpusu
Naudodami dvi SIM korteles ženkliai sumažinsite tarptinklinio ryšio išlaidas
RS232/RS485 sąsajos degalų stebėsenai bei kitiems išoriniams duomenims nuskaityti
Impulsinė įvestis, skirta nuskaityti degalų srauto matuoklių duomenis ir valdyti degalų sunaudojimą
PASIRINKITE TINKAMĄ MODELĮ
GAMINIO SPECIFIKACIJOS
Name
Teltonika TM2500
Technology
GSM/GPRS/GNSS/ BLUETOOTH® LE
GNSS
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Receiver
33 tracking channels
99 acquisition channels
Tracking sensitivity
-165 dBM
Position Accuracy
< 2.5 m CEP
Velocity Accuracy
< 0.1 m/s (within +/- 15% error)
Hot start
< 1 s
Warm start
< 25 s
Cold start
< 35 s
Technology
GSM
2G bands
Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer
GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
Data support
SMS (text/data)
Input voltage range
10 - 30 V DC with overvoltage protection
Internal Back-up battery
170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Power consumption
At 12V < 6 mA (Ultra Deep Sleep)
At 12V < 6,5 mA (Deep Sleep)
At 12V < 7 mA (Online Deep Sleep)
At 12V < 12 mA (GPS Sleep)
At 12V < 38 mA (Nominal with no load)
RS485 input voltage range on A or B pin (common-mode voltage)
-7V to +12V
RS232 input voltage range (common-mode voltage)
+/-15V
RS232 input voltage range (maximum operational voltage)
+/-25V
Specification
4.0 + LE
Supported peripherals
Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Bluetooth® LE sensors support
Dimensions
71 x 67 x 26 mm (L x W x H)
85 x 67 x 26 mm (L x W x H)(length with connector socket)
Weight
79 g
Operating temperature (without battery)
-20 °C to +85 °C
Storage temperature (without battery)
-20 °C to +85 °C
Operating temperature (with battery)
0 °C to +40 °C
Storage temperature (with battery)
-20 °C to +45 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP67
Battery charge temperature
0 °C to +45 °C
Battery discharge temperature
-20 °C to +60 °C
Battery storage temperature
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Digital Inputs
1
Digital Outputs
1
Analog Inputs
1
CAN Adapter Inputs
1
1-Wire
1
RS232
1
RS485
1
GNSS antenna
Internal High Gain
Cellular antenna
Internal High Gain
USB
2.0 Micro-USB
LED indication
2 status LED lights
SIM
Dual SIM
Memory
128MB internal flash memory
Sensors
Accelerometer
Scenarios
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
Sleep modes
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update
FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth® wireless technology)
SMS
Configuration, Events, DOUT control, Debug
GPRS commands
Configuration, DOUT control, Debug
Time Synchronization
GNSS, NITZ, NTP
Fuel monitoring
LLS (Analog), RS232/485 Fuel sensor, LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle
Ignition detection
Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle)
RS232 Modes
Log Mode, NMEA, LLS, LCD, RFIH HID/MF7, Garmin FMI, TCP ASCII/Binary
RS485 Modes
Log Mode, NMEA, LLS, TCP ASCII/Binary
Regulatory
CE/RED, UKCA, E-Mark, RoHS, REACH, Anatel
UŽSAKYMO KODAI
Standartinės pakuotės sudėtis
Standartiniai užsakymo kodai
Specialūs užsakymo kodai
SUSIJĘ PRIEDAI
Patogus sprendimas su kelių lygių paskyromis valdyti sekimo įrenginius nuotoliniu būdu. Su išmaniosiomis grupėmis ir tvarkaraščiais automatiškai atnaujinkite gaminių programinę aparatinę įrangą bei konfigūraciją.
