Reliable 4G connection with fallback to 2G network ensures wide-ranging coverage of your fleet management needs. This model uses a separate module to gather GNSS data and has dual-channel, L1 + L5 support.
Tachograph live data reading via K-Line, Tacho CAN or FMS connections for everyday driver management and fleet efficiency
Read J1939 data that includes standard CAN FMS from heavy vehicles like trucks and raw J1939 data from special machinery, such as construction cranes or electric buses. Possibility to connect to CAN line with multiple nodes.
2x RS232 and 1x RS485 serial communication interfaces for connecting external devices, such as thermographs, sensors, RFID readers and more
CHOOSE THE MODEL FOR YOU
PRODUCT SPECIFICATIONS
Name
FMC650-MBX50: MeiG SLM320-PE2C
Technology
LTE (CaT1) / 2G (GSM / GPRS)
Module name
Airoha AG3335MB
GNSS
GPS, GLONASS, GALILEO, BEIDOU, QZSS
Receiver
L1: 75 acquisition/tracking channel
L5: 60 tracking channel
Tracking sensitivity
-165 dBM
Position Accuracy
< 2.5 m CEP
Hot start
1 s
Warm start
< 25 s
Cold start
< 32 s
Technology
LTE Cat 1, GSM
2G bands
FMC650-MBX50: B2/B3/B5/B8
4G LTE bands
FMC650-MBX50:
LTE-FDD: B1/B3/B7/B8/B20/B28
LTE-TDD: B38/B40/B41
Data transfer
LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL)
GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support
SMS (text/data)
Input voltage range
8–32 V DC with overvoltage (compatible with pulse 5a and pulse 5b) and reverse polarity protection
Internal Back-up battery
550 mAh Ni-Mh, 8.4 V battery
2 W max. Current consumption at 12 V
At 12V < 4 mA (Deep Sleep)
At 12V < 11 mA (Online Deep Sleep)
At 12V < 32 mA (GPS Sleep)
At 12V < 45 mA (nominal with no load)
At 12V < 0.25 A Max. (with full Load / Peak)
2 W max. Current consumption at 24 V
At 24V < 2,9 mA (Deep Sleep)
At 24V < 7 mA (Online Deep Sleep)
At 24V < 17 mA (GPS Sleep)
At 24V < 35 mA (nominal with no Load)
RS485 input voltage range on A or B pin (common-mode voltage)
-7V to +12V
RS232 input voltage range (common-mode voltage)
+/-15V
RS232 input voltage range (maximum operational voltage)
+/-25V
Supported peripherals
Temperature and Humidity sensor, Universal BLUETOOTH® LE sensors support
Name
Blue NRG232
Specification
5.2 + LE
Dimensions
104,1 x 76,8 x 31,5 mm (L x W x H)
Weight
201 g
Operating temperature (without battery)
-40 °C to +85 °C
Storage temperature (without battery)
-40 °C to +85 °C
Battery charge temperature
0 °C to +45 °C
Battery discharge temperature
-20 °C to +60 °C
Operating humidity
5% to 95% non-condensing
Battery storage temperature
-20 °C to +45°C
Ingress Protection Rating
IP41
Battery storage temperature
-20 °C to +45°C
Digital Inputs
4
Digital Outputs
4
Analog Inputs
4
1-Wire
1
RS232
2
RS485
1
CAN J1939
2
J1708
1
K-line
1
GNSS antenna
External High Gain (L1+L5)
Cellular antenna
External High Gain
USB
2.0 Mini-USB – device can be powered by USB for easier device configuration
LED indication
2 status LED lights
SIM
2x SIM Card (Dual-SIM) or 1x eSIM
Memory
2.0 Mini-USB – device can be powered by USB for easier device configuration
Switchable CAN terminals
Supported on CAN1 and CAN2 lines
Sensors
Accelerometer
Scenarios
Green/Eco Driving, Over Speeding detection, Jamming detection, Excessive Idling detection, Towing detection, Crash detection, Immobilizer, iButton Read Notification
Functionalities
Auto Geofencing, Manual Geofencing, Trip detection, Odometer, DDD download and Tacho online data, Offline tracking
Supported peripherals
Garmin, RFID RS232, RFID 1-Wire, iButton 1-Wire, Temperature 1-Wire, LV-CAN200, CAN FMS (J1939, J1708), K-line data, Continental tire pressure measurement sensor, Iridium SBD (Iridium Edge/TSM232), Carrier freezer, Log Mode, NMEA, TCP ASCII/Binary, Temperature and humidity sensor, Universal BLE® sensors support
Sleep modes
GPS Sleep, Online Deep Sleep, Deep Sleep
Configuration and firmware update
FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®)
SMS
Configuration, Events, DOUT control, Debug
GPRS commands
Configuration, DOUT control, Debug
Time Synchronization
GNSS, NITZ, NTP
Fuel monitoring
LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, CAN FMS, Ultrasonic level sensor
Ignition detection
Digital Input, Accelerometer, External Power Voltage
RS232 Modes
Log Mode, NMEA, LLS, LCD, RFIH HID/MF7, Garmin FMI, TCP ASCII/Binary
RS485 Modes
LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, CAN FMS, Ultrasonic level sensor
Regulatory
CE-RED, UKCA, E-mark, RCM, Pulse 5a, SIRIM QAS, ICASA, CITC
