PRODUCT USE CASES
View all
Define your own data sending scenarios by the type of the asset you are tracking or a dedicated use case
Quick set-up with Teltonika vehicle tracking devices to use TAT100 as a backup tracker for your transport’s maximum safety
Various usage scenarios to increase battery lifetime depending on your needs
Fast device set-up without any wires and protection in extreme weather conditions with the IP68-rated casing
CHOOSE THE MODEL FOR YOU
PRODUCT SPECIFICATIONS
Name
TAT100-TAIB0: Teltonika TM2500
TAT100-TAIBA: Teltonika TM2500
Technology
2G(GSM/GPRS)/GNSS/BLUETOOTH ® LE
GNSS
L1: GPS, GLONASS, GALILEO, BEIDOU, SBAS*, QZSS*, DGPS*, AGPS*
* Optional modes available with custom firmware applications, for more information contact your sales manager.
Receiver
33 tracking channels
99 acquisition channels
Tracking sensitivity
-165 dBM
Position Accuracy
< 2.5 m CEP
Technology
GSM/GPRS
2G bands
Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer
GSM (GPRS): Max. 85.6 Kbps (DL) / Max. 85.6 Kbps (UL)
Data support
SMS (text/data)
Internal battery
TAT100-TAIB0:
2200mAh, 2S, extremely low self-discharge Li-SOCl2
batteries 7.2V, Non-rechargeable
TAT100-TAIBA:
2200mAh, 3S, extremely low self-discharge Li-SOCl2
batteries 10.8V, Non-rechargeable
Battery life
TAT100-TAIB0:
2-cell battery:
Up to 5 years (when used as a backup tracker only via Bluetooth®)*
Up to 4 years (1 LBS – cell towers report per day)*
Up to 3 years (1 GNSS report per day)*
TAT100-TAIBA:
3-cell battery:
Up to 6 years (when used as a backup tracker only via Bluetooth®)*
Up to 5 years (1 LBS – cell towers report per day)*
Up to 4 years (1 GNSS report per day)*
*Battery life estimates are influenced by many factors such as outdoor temperature, frequency of reporting, installation, and orientation of the device, network coverage, additional functionalities (like Bluetooth® scanning enabled) and more.
Specification
4.2 + LE
Supported peripherals
EYE Sensors, EYE Beacons (recovery mode only), Universal Bluetooth® LE sensors support
Dimensions
78 x 63 x 28 mm (L x W x H)
Weight
TAT100-TAIB0: 119g (with 2 cells battery)
TAT100-TAIBA: 138g (with 3 cells battery)
Operating temperature (with battery)
-35 °C to +75 °C
Storage temperature (with battery)
-40 °C to +85 °C (Recommended max. 30°C)
Operating temperature (without battery)
-20 °C to +60 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP68
Battery discharge temperature
-60 °C to +85 °C
Battery storage temperature
Recommended max. 30°C
GNSS antenna
Internal High Gain
Cellular antenna
Internal High Gain
USB
2.0 Micro-USB
LED indication
2 status LED lights
SIM
Micro-SIM
Memory
128MB internal flash memory
Sensors
Accelerometer
Scenarios
Accelerometer wake up, GNSS and LBS, Bluetooth® LE sensors support, Recovery mode, Periodic tracking on stop / on move, Scheduler with time zones, Backup tracking, Static navigation, Lost Bluetooth® LE sensors
Sleep modes
Single custom sleep mode
Configuration and firmware update
FOTA WEB, Teltonika Configurator (USB)
SMS
Configuration, Events, Debug
GPRS commands
Configuration, Debug
Time Synchronization
GNSS, NITZ, NTP
Regulatory
CE/RED, E-Mark, EAC, UKCA, UA.TR, REACH, RoHS, Anatel, SIRIM QAS
