Fleet Telematics (FT) platform offers advanced firmware and hardware, taking your tracking experience to the next level
More precise GNSS with up to 41 visible satellites, enabling considerably higher tracking quality for location-based services
The ultimate protection against dust, high pressure water, and steam
Optimised sleep modes allow the device to operate on its own for an extended period of time and significantly reduce vehicle battery drainage
CHOOSE THE MODEL FOR YOU
PRODUCT SPECIFICATIONS
Model name
FTM880-Q3AB0
Model name
FTM880-Q3AB0: Quectel BG95-M3 with AG3335
Technology
LTE CAT M1/NB-IoT/GPRS/GNSS
GNSS
GPS, GLONASS, GALILEO, BEIDOU
Receiver
L1: 75 channel
Tracking sensitivity
-165 dBM
Position Accuracy
< 1.5 m CEP
Velocity Accuracy
< 0.1 m/s (within +/- 15% error)
Hot start
< 1 s
Warm start
< 25 s
Cold start
< 35 s
Technology
LTE CAT M1/NB-IoT/GSM
2G bands
FTM880-Q3AB0: GSM: B2/B3/B5/B8
4G LTE bands
FTM880-Q3AB0:
LTE FDD (CAT M1): B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85
LTE-TDD (CAT NB2): B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85
Data transfer
LTE FDD (CAT M1): Max. 588 Kbps (DL) / Max. 1119 Kbps (UL)
LTE TDD (CAT NB2): Max. 127 Kbps (DL) / Max. 158.5 Kbps (UL)
GSM (GPRS): Max. 107 Kbps (DL) / Max. 85.6 Kbps (UL)
Transmit power
Class 4 for GSM850/900: 33±2dBm Class 1 for GSM1800/1900: 30±2dBm
Class 3 for LTE-TDD: 20±2dBm Class 3 for LTE-FDD: 20±2dBm
Data support
SMS (TEXT, PDU), Network protocols (TCP, UDP)
Codec support
Codec 8 Extended
Input voltage range
10-30 V DC
Internal Back-up battery
320 mAh Li-Ion battery 3.7V (1.18 Wh)
Internal fuse
3 A
Power consumption
At 12V < 24.523mA Normal mode
At 12V < 5.601mA Online Deep Sleep mode
At 12V < 2.552mA Deep Sleep mode
At 12V < 0.599mA Power off Sleep
Dimensions
118 x 48 x 18.5 mm (L x W x H)
Weight
118 g
Operating temperature (without battery)
-30 °C to +85 °C
Storage temperature (without battery)
-30 °C to +85 °C
Operating temperature (with battery)
0 °C to +45 °C
Storage temperature (with battery)
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP69K
Battery charge temperature
0 °C to +45 °C
Battery discharge temperature
-20 °C to +60 °C
Battery storage temperature
-10 °C to +50 °C for 1 month
-10 °C to +35 °C for 3 months
0 °C to +30 °C for 1 year
Connection
U-Type cable
GNSS antenna
Internal High Gain
Cellular antenna
Internal High Gain
USB
2.0 USB Type-C
LED indication
2 status LED lights
SIM
Nano-SIM
Memory
128MB internal flash memory
Sensors
Accelerometer
Scenarios
Green Driving, Over Speeding detection, Jamming detection, Excesive idling detection, Unplug detection, Crash Detection, Auto Geofence, Trip
Sleep modes
Deep Sleep, Online Deep Sleep, Power Off Sleep
Configuration and firmware update
FOTA WEB, Teltonika Configuration Tool (TCT)
SMS
Configuration, Debug
GPRS commands
Configuration, Debug
Time Synchronization
GNSS, NITZ, NTP
Ignition detection
Accelerometer, External Power Voltage
Regulatory
CE/RED, E-Mark, RCM, UK CA
