Obtenha os dados reais do hodômetro e do nível de combustível
Basta conectar o dispositivo na porta OBD-II e iniciar o rastreamento
Trazendo novo valor e expandindo os cenários de uso com mais de 110 veículos suportados no mercado de VE
Lista de veículos suportados com todos os modelos e parâmetros do fabricante disponíveis
Name
Teltonika TM2500, MeiG SLM320-E, MeiG SLM320-LA
Technology
LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH® LE
GNSS
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Receiver
33 tracking channel
99 acquisition channel
Tracking sensitivity
-165 dBM
Position Accuracy
< 2.5 m CEP
Velocity Accuracy
< 0.1 m/s (within +/- 15% error)
Hot start
< 1 s
Warm start
< 25 s
Cold start
< 35 s
Technology
LTE Cat 1/GSM
2G bands
GSM: B2/B3/B5/B8
4G LTE bands
SLM320-E: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41 SLM320-LA: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40
Data transfer
LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Transmit power
Classe 4 para GSM850/900: 23±2dBm
Classe 1 para GSM1800/1900: 20±2dBm
Classe 3 para LTE-TDD: 23±2,7dBm
Classe 3 para LTE-FDD: 23±2,7dBm
Data support
SMS (text/data)
Input voltage range
10 - 30 V DC with overvoltage protection
Internal Back-up battery
170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Power consumption
At 12V < 3 mA (Ultra Deep Sleep)
At 12V < 5 mA (Deep Sleep)
At 12V < 16 mA (Online Deep Sleep)
At 12V < 18 mA (GPS Sleep)
At 12V < 33 mA (nominal with no load)
At 12V < 2A Max. (with full Load / Peak)
Specification
4.0 + LE
Supported peripherals
Temperature and Humidity sensor, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support
Dimensions
67,2 x 49,6 x 25 mm (L x W x H)
Weight
63 g
Operating temperature (without battery)
-40 °C to +85 °C
Storage temperature (without battery)
-40 °C to +85 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP41
Battery charge temperature
0 °C to +45 °C
Battery discharge temperature
-20 °C to +60 °C
Battery storage temperature
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Data
HS CAN, MS CAN, SW CAN, K-line
Data reading
OEM Fuel level, odometer and up to 32 vehicle onboard parameters, supported OBD protocols:
ISO 9141-2 (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (fast init, 10.4 kbaud)
ISO 15765-4 CAN (11 bit ID, 250 kbaud)
ISO 15765-4 CAN (11 bit ID, 500 kbaud)
ISO 15765-4 CAN (29 bit ID, 250 kbaud)
ISO 15765-4 CAN (29 bit ID, 500 kbaud)
ISO 14229 (UDS)
J2819 (VW TP2.0)
Connection
OBDII Socket
GNSS antenna
Internal High Gain
Cellular antenna
Internal High Gain
USB
2.0 Micro-USB
LED indication
2 status LED lights
SIM
Micro-SIM
Memory
Memória flash interna de 128Mb
Sensors
Accelerometer
Scenarios
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
Sleep modes
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update
FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®)
SMS
Configuration, Events, Debug
GPRS commands
Configuration, Debug
Time Synchronization
GNSS, NITZ, NTP
Fuel monitoring
OBDII, OEM fuel level
Ignition detection
Accelerometer, External Power Voltage, Engine RPM
Regulatory
CE/RED, UKCA, E-Mark, EAC, RoHS, REACH, CITC, Anatel, RCM, SDPPI POSTEL, SIRIM QAS
O pacote padrão contém
Códigos de pedido padrão
Códigos de pedido personalizados
Solução sofisticada de gerenciamento de dispositivos remotos com hierarquia de contas multinível. Crie grupos e agendamentos inteligentes para automatizar a atualização de firmware e configuração.
